Ultra-Flexible Power Distribution Cables and Turnkey High-Voltage Cable Assemblies with Glenair Signature Connectors
Series 96
Power distribution cables present a unique challenge to electrical wire interconnect system engineers. Typically fabricated from stiff, non-flexible conductors and jackets with extremely large bend radii, such cables are heavy, hard to route, and prone to insulation damage from weathering and abrasion. TurboFlex® power distribution cables — and complex high-voltage cable assemblies — are constructed from high strand-count rope-lay inner conductors made with tin, nickel, or silver-plated copper, nickel-plated aluminum, or bare copper. These highly-flexible conductors, combined with Glenair's high-performance Duralectric™ insulation result in cables ideally suited for applications where flexibility, durability, and weight reduction are required. The signature Duralectric™ insulation compound provides outstanding resistance to temperature extremes, ozone exposure, caustic chemicals including jet fuel, gamma radiation, and other forms of environmental and mechanical damage. Long life and performance are critical in power distribution applications. TurboFlex, with its flexible conductors and Duralectric™ jacketing delivers both.
The TurboFlex Ecosystem: Cables, Contacts, Connectors, and Accessories
Reference
- TurboFlex® Overview
- Product Selection Guide
- The TurboFlex® Ecosystem: High-Power/High-Voltage Cables, Contacts, Connectors, and Assemblies
- Detailed Wire Selection Guide
- TurboFlex® Test Reports
- TurboFlex® Aluminum and Copper Comparison Tables
Insulation StrippingWire Crimping
Technical Datasheets
- Duralectric™ D Performance Specifications
Duralectric™ D is a high-performance elastomeric material for use as wire insulation, cable jacketing, conduit jacketing, cable/conduit overmolding, and Autoshrink™ tubing and boots. - Duralectric™ L Performance Specifications
Duralectric™ L (light) is a high-performance elastomeric material for use as lightweight wire insulation, cable jacketing, conduit jacketing, and cable/conduit overmolding. - Duralectric™ K Performance Specifications
Duralectric™ K is a high-performance elastomeric material for use as wire insulation, cable jacketing, conduit jacketing, and cable/conduit overmolding. - Duralectric™ F Performance Specifications
Duralectric™ F is a high-performance elastomeric material for use as cable jacketing, conduit jacketing, cable/conduit overmolding, and Autoshrink™ tubing and boots. - Duralectric™ C Performance Specifications
Duralectric™ C is an electrically conductive elastomeric material used to control the electric field in high-voltage cable applications.
Related Glenair Content
- Duralectric™ Jacketing Material
- M27500 and M22759 Type Wire and Wire Harness Assembly Cable / Series 96
- Integrated Systems — Turnkey, Precision-Machined Structural Components / Enclosures plus Glenair-Built Interconnect Cabling
Make a Request!
Glenair Video Library
TurboFlex® Flexible Power Distribution Cables
Ultra-Flexible Power Distribution Cables and Turnkey High-Voltage Cable Assemblies with Glenair Signature Connectors
Series 96
TurboFlex® Power Distribution Cables
967-601
TurboFlex® M AS22759-type conductor, Duralectric™ D Insulation, with Jacket and Braided EMI Shielding, 725-2875 VAC (Imperial)
967-602
TurboFlex® M AS22759-type conductor, Duralectric™ D Insulation, braided EMI shield, and Fabric Overbraid, 725-2875 VAC (Imperial)
961-161
TurboFlex® Copper Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 3000 VAC (Imperial)
961-007
TurboFlex® Copper Core, Dual-Layer Duralectric™ D Insulation/Jacket, Metallic Braided Shield, 3000 VAC (Imperial)
961-129
TurboFlex® Copper, Dual-Layer Duralectric™ D Thin-Wall Insulation/Jacket, Metallic Braided Shield, 2000 VAC (Imperial)
961-143
TurboFlex® Copper, Dual-Layer Duralectric™ D Ultra-Thin Insulation/Jacket, Metallic Braided Shield, 1000 VAC (Imperial)
961-163
TurboFlex® Copper, Dual-Layer Duralectric™ D Insulation/Jacket, Microfilament Braided Shield, 3000 VAC (Imperial)
961-153
TurboFlex® Copper, Dual-Layer Duralectric™ D Insulation/Jacket, Microfilament Braided Shield, 3000 VAC (Imperial)
961-155
TurboFlex® Copper, Dual-Layer Duralectric™ D Insulation/Jacket, Microfilament Braided Shield, 2000 VAC (Imperial)
961-157
TurboFlex® Copper, Dual-Layer Duralectric™ D Insulation/Jacket, Microfilament Braided Shield, 1000 VAC (Imperial)
961-044
TurboFlex® Copper Core, Duralectric™ D Insulation and Fabric Overbraid, 2000-4500 VAC (Imperial)
961-113
TurboFlex® Copper, Triple-Layer Duralectric™ D/C (HPHV) Insulation, ArmorLite Shield, and Duralectric™ L Jacket (Imperial)
961-033
TurboFlex® Copper Core, Duralectric™ K Insulation, 1000–3000 VAC, -110°C – +200°C (Imperial)
960-3300
TurboFlex® Copper Core, Duralectric™ D Jacket, 3000 VAC 3-Phase Symmetric with Drain Wire (Imperial)
960-3301
TurboFlex® Copper Core, Duralectric™ D Jacket, 3000 VAC 3-Phase with Full-Size Ground (Imperial)
960-3302
TurboFlex® Copper Core, Duralectric™ D Jacket, 3000 VAC 3-Phase with full-Size Ground and Signal (Imperial)
961-162
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 3000 VAC (Imperial)
961-145
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 3000 VAC (Imperial)
961-147
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 2000 VAC (Imperial)
961-150
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 1000 VAC (Imperial)
961-164
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets, Microfilament Braided Shield, 3000 VAC (Imperial)
961-154
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets, Microfilament Braided Shield, 3000 VAC (Imperial)
961-156
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets, Microfilament Braided Shield, 2000 VAC (Imperial)
961-158
TurboFlex® Aluminum Core, Dual-Layer Duralectric™ D Jackets, Microfilament Braided Shield, 1000 VAC (Imperial)
961-167
TurboFlex® Aluminum Core, Duralectric™ D Insulation and Fabric Overbraid, 1000-3500 VAC (Imperial)
