MIL-DTL-26482 Series I and II Type Hermetic Seal Connectors

Fast and Reliable Mating

Glenair MIL-DTL-26482 Series I and II Bayonet-Lock Connectors are ideally suited for vacuum chambers and other military and commercial applications that utilize this general purpose medium density cylindrical connector and require helium leak test rates of less than 1x10^-7 cc/second. The bayonet mechanism provides fast and easy coupling, especially when the connector is situated in an awkward or hard to reach location. A wide range of available mounting styles–including both narrow and wide flange mounts–provide complete flexibility in interconnect system design. PCB and solder cup contacts allow easy integration and termination to I/O cabling and electronic sub-systems. Glenair MIL-DTL-26482 Type hermetics are interchangeable and intermateable with the wide range of industry-standard bayonet connectors designed around MIL-DTL-26482 and/or qualified to VG 95328, including ITT Cannon KPT.

MIL-DTL-26482 Type

• Insert Arrangements per MIL-DTL-1669
• Key/Keyway Positions
• Special Leak Rate Mod Codes

Glenair Hermetic Connector Products

• Special Leak Rate Mod Codes
• Space Grade Application Guide

Hermetic Connectors > Section D

---

MIL-DTL-26482 Series I Type Hermetic

	230-014 Bayonet Coupling Solder Mount Receptacle MIL-DTL-26482 Series I Type Hermetic MS3113 Type
	230-015 Bayonet Coupling Jam Nut Receptacle MIL-DTL-26482 Series I Type Hermetic MS3114 Type
	230-035 Bayonet Coupling Narrow Flange Mount Receptacle MIL-DTL-26482 Series I Type Hermetic MS3112 Type
	237-133 Square Flange Mount Receptacle with Bayonet Coupling and Solder Cup Termination MIL-DTL-26482 Series I Hermetic MS3112 Type
	947-303 Narrow Flange Mount Bulkhead Feed-Thru MS3440 Type
	237-240 Special Square Flange Mount Receptacle with Bayonet Coupling and Solder Cup Termination MIL-DTL-26482 Series I Type Hermetic

MIL-DTL-26482 Series II Type Hermetic

	230-016 Bayonet Coupling Narrow Flange Mount Receptacle MIL-DTL-26482 Series II Type Hermetic MS3440 Type
	230-017 Bayonet Coupling Wide Flange Mount Receptacle MIL-DTL-26482 Series II Type Hermetic MS3442 Type
	230-018 Bayonet Coupling Solder Flange Mount Receptacle MIL-DTL-26482 Series II Type Hermetic MS3443 Type
	230-019 Quick Release Bayonet Receptacle Single Hole Jam-Nut Mount MIL-DTL-26482 Series II Type Hermetic MS3449 Type
	230-034 Bayonet Coupling Jam-Nut Mount Receptacle MIL-DTL-26482 Series II Type Hermetic MS3449 Type
	230-043 Bayonet Coupling Jam-Nut Receptacle with Accessory Threads MIL-DTL-26482 Series II Type Hermetic
	230-044 Bayonet Coupling Jam-Nut Receptacle with Banding Porch MIL-DTL-26482 Series II Type Hermetic
	947-292 Bayonet Coupling Jam Nut Mount Pin-Socket Bulkhead Feedthrough Receptacle MIL-DTL-26482 Series II Type Hermetic
	257-135 Bayonet Coupling Jam Nut Mount Pin-Pin Bulkhead Feedthrough Receptacle MIL-DTL-26482 Series II Type Hermetic
