Composite Interconnect Component Assembly Tools

One Stop Shopping for All Your Backshell, Connector, and Cable Assembly Requirements

Glenair addresses interconnect system assembly requirements with a variety of military standard and specialized connector-to-backshell assembly tools, braided shielding banding tools and accessories. Our tool line for composite components includes connector wrenches, as well as universal connector holding tools for production use as well as field maintenance.

Glenair's connector and backshell holding tools and wrenches ensure fast and reliable assembly of interconnect components to correct torque levels — a critical issue with all types of coupling systems. Special designs fit the unique knurling on composite connectors and backshells.

Glenair's Band-It® Termination System for braided metal and composite shielding includes both hand-held and bench-mounted units. The Band-It® Termination System provides fast and reliable shield terminations which pass the most stringent shock, vibration and thermal tests. The low-profile and smooth inside diameter of the one-piece austenitic stainless steel clamping band virtually eliminates RFI/EMI leakage paths.

Reference

• General Information
• Composite Connector Accessory-to-Connector Assembly Procedures
• Backshell Shield Termination Assembly Instructions

Glenair Video Library

• Composite Backshell Assembly Procedure

Composite Thermoplastic > Section G

---

	TG69 Soft Jaw Pliers TG69 Soft Jaw Pliers
	600-091 Composite Connector Accessory Coupling Nut Wrench
	600-157 Composite Connector Accessory Coupling Nut Wrench
	TG70 Strap Wrench These wrenches are made of the following materials: Wrench Handle - Aluminum Alloy/Nickel Plate. Wedge - Stainless Steel/Passivated. Strap - Impregnated Fabric. Straps are 1/2 inch (12.7) in width. Replacement straps are available. Specify part number G70515-xx for 12, 18, 24 or 36-inch strap. 24 and 36 inch for double wrap. Metric dimensions (mm) are indicated in parentheses. Double wrap as shown for heavy duty range. Not recommended for composite coupling nuts (use 600-091 or 600-157
	600G161 Digital Torque Wrench, 600-162B and 600-162BV Bench Stand 600G161 Torque Wrench 600-162B Digital Torque Wrench Bench Stand 600-162BV Digital Torque Wrench Vertical Bench Stand
	600-164 Large Broad Blade Utility Shear for Cutting Metal-Clad Composite Braided Shielding Also Cuts Rubber, Cable Jacketing, Cable, Plastics and Rope
	600-058 and 600-061 Hand Banding Tool and Hand Micro Banding Tool
	600-052, 600-090, 600-057, 600-083, 600-052-1, 600-090-1, 600-057-1 and 600-083-1 Clamping Bands
	600-056, 600-062, 600-060 and 600-082 Banding Tool Replacement Part Kits
	600-055, 600-072-1 and 600-086-1 600-055 Calibration Key 600-072-1 Standard 600-086-1 Micro Banding Tool Tension Gauges
