MIL-DTL-38999 QPL and Glenair Signature Hermetic Seal Connectors

MIL-DTL-38999 Series I, II, III, and IV Family of Hermetic Connectors

Glass-to-Metal Seal D38999 Hermetics

MIL-DTL-38999 Series I, II, III, and IV hermetic connectors are ideal for high-pressure/low-leakage applications in air, sea and space environments. Glenair is on the Qualified Product List (QPL) for all configurations of MIL-DTL-38999 Series I through IV pin and socket hermetic connectors. We also offer our D38999 type commercial part numbers (Glenair SuperNine) for applications that do not require MS qualified products but want to take advantage of additional features available in the Glenair signature series. And because Glenair makes all its hermetic connectors in-house, including the machining of shells, molding of interfacial seals, and firing of hermetic components, we can offer you outstanding availability on stock products and fast turnaround on special orders.

Reference

• Quick Selection Guide
• Insert Arrangements (IAW MIL-STD-1560)
• Layouts and Pin Counts
• Material Specifications
• Hermetic Connector Performance Specifications
• D38999 Hermetic Contact Materials and Performance Specifications
• Recommended Torque Values
• Hermetic Connectors and Environmental Mates
• Additional MIL-DTL-38999 Series Connectors (Environmental, Filter, Fiber Optic, etc.)

Alternate Keyway Positions

• MIL-DTL-38999 Series I and II
• MIL-DTL-38999 Series III
• MIL-DTL-38999 Series IV

Hermetic Connectors > MIL-DTL-38999

---

On this page...

• MIL-DTL-38999 Series I QPL and Glenair Signature Hermetic Connectors
• MIL-DTL-38999 Series II QPL and Glenair Signature Hermetic Connectors
• MIL-DTL-38999 Series III QPL and Glenair Signature SuperNine Hermetic Connectors
• SuperNine Series III Lightweight Hermetic Connectors with CODE RED Encapsulant
• MIL-DTL-38999 Series IV QPL and Glenair Signature SuperNine Hermetic Connectors

---

Reference

• Insert Arrangements (IAW MIL-STD-1560) - Pin Face View
• Layouts and Pin Contact Counts - per MIL-STD-1560
• Hermetic Class Materials and Finishes
• Hermetic Connector Performance Specifications
• Hermetic Contact Materials and Performance Specifications
• MIL-DTL-38999 Series I and II Alternate Keyway Positions
• Recommended Torque Values
• Hermetic Connectors and Environmental Mates

"Mission-Critical" Hermetic Sealing with 1x10^-7 Leak-Rate Performance

Hermetically-sealed interconnects used in vacuum or high-altitude applications prevent moisture and other contaminants from damaging sensitive electronic equipment. Glass-to-metal hermetic sealing has been the gold standard in the aerospace and petrochemical industries for decades due to the strength and long-term durability of the materials used. But glass-to-metal seal hermetics come with a big price tag in both weight and electrical resistance.

CODE RED is an innovative sealing encapsulant and application process — invented by Glenair — that provides durable hermetic sealing in a lightweight aluminum package. CODE RED allows for the use of conventional gold-plated copper alloy contacts, significantly improving electrical performance. CODE RED hermetic connectors are available now in Glenair SuperNine® (D38999 Series III type), Series 80 Mighty Mouse, and M24308 D-Sub. These connectors deliver reliable, life-of-system 1x10^-7 max leak-rate hermetic sealing and special non-magnetic (zero residual magnetism) versions are also available, consult factory.

Reference

• Overview: SuperNine Lightweight Hermetic Connectors with CODE RED Encapsulant
• "Mission-Critical" Hermetic Sealng Solution

Hermetic-class DLA certified MIL-DTL-38999 Series IV connectors from Glenair provide hermetically sealed breech lock connectors for high shock and vibration applications. Breech-lock systems provide robust engagement augmented by an internal mechanical thread to ensure connectors remain mated.

DLA-QPL MIL-DTL-38999 Series III Available from Glenair

• Qualified hermetic jam‐nut, weld, solder and panel mount receptacles
• All 1560 crimp-contact insert arrangements fully supported
• N and Y plating classes, plus Glenair COTS equivalents
• 100% made in America, no foreign-sourced materials, component parts, or assembly labor employed

Reference

• Overview: MIL-DTL-38999 Series IV Hermetic
• Industry Standard, Hermetic Triple-Start Mating, MIL Qualified Connectors
